REA JET DOD 2.0

Controller Unit


Large Character Inkjet Printer - New Generation 2.0

  • Full Unicode support: all global languages can be printed for companies with international customers

  • Support of all True Type Fonts (TTFs): maximum design flexibility for your print

  • XML-based data structure and communication protocol: globally used standard for data compatibility

  • Sturdy and high-quality stainless-steel casing designed for daily work in rough industry environments

  • 24V power supply: for direct integration into machines and systems

  • Multi voltage power supply available: for immediate global use

  • Protection Class IP65: dust-proof and water-resistant for rigorous industrial use

  • Uniform communication protocol for condition monitoring across multiple devices: allows user-specific signal processing

  • Consistent graphical user interface WYSIWYG: realistic display of print contents

Get connect

  • Power supply 24V DC out of SELV-Power Supply

  • External power adaptor IP67 (100V-277 VAC, 50-60 Hz)

  • Ethernet interface 100Mbit/s M12-D-coded for faster data exchange

  • Serial interface RS232/422

  • USB interface

  • Digital I/O interface, freely programmable (e.g. information on filling level)

  • 2 print head connection pipes: up to 512 channels (nozzles) selectable

  • Example 1: 16 print heads with each 32 nozzles (512 nozzles fully used)

  • Example 2: 8 print heads with each 16 nozzles (128 nozzles of 512 used)

  • Product sensor port and shaft encoder

REA JET DOD 2.0 - Controller Unit
